Single Permanent Magnetic Drum Separator Machine
₹185,000.00
Description
Permanent Magnetic Drum Separator Overview & Separation Mechanism
The Single Permanent Magnetic Drum Separator Machine manufactured by N.S. Engineering Works is designed for continuous, automatic extraction of tramp iron and fine ferrous contaminants from granular, crushed, and bulk material streams. Fabricated at our Mandi Gobindgarh industrial works with high-grade SS-304 stainless steel shells and heavy-duty structural channel framing, this machine provides round-the-clock protection for crushing circuits, pulverizers, and downstream processing equipment.
The operational principle incorporates a stationary 180-degree high-gradient permanent magnetic arc positioned inside a rotating outer cylinder shell. As incoming raw feed is metered uniformly across the drum surface by a vibratory feeder or chute, ferrous particles are immediately drawn and pinned to the stainless steel shell. The rotating shell transports the trapped iron past the stationary magnetic cutoff boundary, where the magnetic field terminates, dropping the clean tramp iron into an isolated discharge chute while non-magnetic product discharges freely off the drum periphery.
Standard Magnetic Drum Separator Range & Capacities
We fabricate customized single and double drum configurations tailored to match conveyor widths, flow rates, and specific mineral or scrap densities:
Key Structural & Engineering Features
Lifetime Permanent Magnet System
Built with zero-demagnetization Rare Earth NdFeB or high-density Strontium Ferrite blocks. Requires no electrical excitation, ensuring zero operating power cost for magnetism.
Wear-Resistant SS-304 Shell
The outer rotating drum is rolled from high-thickness non-magnetic stainless steel plate with raised lifter cleats to prevent abrasive wear and slippage of recovered metal scrap.
Heavy Structural Channel Base
Fabricated from heavy 3" × 6" MS channels and 65×65×5 mm MS angles to withstand extreme shock loads and continuous multi-shift plant operation.
Automatic Continuous Self-Cleaning
Eliminates manual operator intervention. Captured metal fragments discharge automatically into the reject chute without stopping plant throughput.
Core Industrial Applications
- Steel Melting Plants & Slag Recovery: Separating valuable metallic iron from furnace slag, ash, and refractory rubble.
- Foundry Sand Reclamation: Extracting core wires, chilled iron shots, and metallic flashing from used foundry molding sand.
- Metal Recycling & Scrap Shredders: Segregating ferrous metal fragments from non-ferrous shredded aluminium, copper, and plastic waste.
- Cement, Minerals & Glass Plants: Preventing crusher and pulverizer damage by removing broken drill bits, bucket teeth, and tramp iron.
- Grain, Sugar & Food Processing: High-purity food-grade separation of fine rust and iron filings before milling or bagging.
Available Plant Accessories & Upgrades
- Vibratory Feeder Assembly: Complete electromagnetic or unbalance motor feeder ensuring a single-layer feed stream across the drum width.
- Heavy Regulated Feed Hopper: Fabricated from 3-4 mm MS plate with adjustable flow gate and wear-resistant liners — Request Hopper Quote
- Dual Splitter Discharge Chute: Fabricated collection duct separating clean material and scrap metal into independent conveyors or collection bins.
- Dust-Tight Enclosure Casing: Fully enclosed mild steel or stainless steel housing with inspection windows and suction ports for fine powders.
12-Month Factory Warranty & Dispatch Terms
Every magnetic drum separator is fabricated, dynamically balanced, and tested under simulated load conditions at our Mandi Gobindgarh workshop. All units carry a 12-month standard manufacturer warranty against fabrication and mechanical defects.
Commercial Terms: 50% advance with formal purchase order, 30% during manufacturing progress, and balance 20% prior to dispatch / trial run. Pan-India road transport and export packaging supported.
Need Higher Purity Two-Stage Recovery? Explore Double Drum Separator
For mineral beneficiation, quartz sand, sponge iron, or applications where 99.5%+ ferrous recovery is needed, we manufacture the Double Magnetic Drum Separator Machine (900 mm × 1200 mm, 15 TPH). The two-stage sequential cascade ensures any fine magnetic particles missed in the first stage are completely captured by the second drum.
Explore Related Mineral Beneficiation & Crushing Machinery
- Double Magnetic Drum Separator Machine (900 × 1200 mm, 15 TPH) • Two-Stage High Purity Recovery
- Jaw Crusher Machine (300 × 500 mm Primary Single Toggle) • Mining & Quarry Stone Crushing
- Vibratory Screens Machine (16 ft × 5 ft Double Deck, 100 TPH) • High Capacity Aggregate Sizing
- Complete Industrial Machine Catalog • Mandi Gobindgarh Direct Workshop Supply
Additional information
| Equipment type | Permanent Magnetic Drum Separator |
|---|---|
| Drum dimensions | 30 Inch Length × 16 Inch Diameter |
| Magnet type | High-Intensity NdFeB / Strontium Ferrite |
| Magnetic field intensity | 2,500 to 4,500+ Gauss |
| Drum shell material | Non-Magnetic Stainless Steel (SS-304) |
| Chassis frame | Heavy 3" × 6" MS Channel & 65×65 mm Angle |
| Motor requirement | 2 HP × 1440 RPM with Gearbox |
| Discharge operation | Continuous Self-Cleaning Auto Discharge |
| Separation efficiency | Up to 99.5% Ferrous Extraction |
